Monohulls: Based on loaded displacement
10,000 lb displacement:

Drogue would have 100 cones on 167' line with a 75' leader; total of 242'. Line would be 5/8" nylon double braid tapering to ½" nylon double braid for the last 75 cones.

15,000 lb displacement:

Drogue would have 107 cones on 179' line with a 75' leader; total of 254'. Line would be 5/8" nylon double braid tapering to ½" for the last 75 cones.

20,000 lb displacement:

Drogue would have 116 cones on 194' line with a 75' leader; total of 269'. Line would be 3/4" at forward end tapering to ½" for the last 75 cones.

25,000 lb displacement:

Drogue would have 124 cones on 207' line with a 75' leader; total of 282'. Line would be 3/4" nylon double braid, tapering to ½" for the last 75 cones.

30,000 lb displacement: Drogue would have 132 cones on 220' line with a 75' leader; total of 295'. Line would be 3/4" nylon double braid, tapering to ½" for the last 75 cones.

35,000 lb displacement: Drogue would have 139 cones on 232' line with a 75' leader; total of 307'. Line would be 3/4" nylon double braid, tapering to ½" for the last 75 cones.

40,000 lb displacement: Drogue would have 147 cones on 320' line.Line should taper from 7/8" or 1" to ¾" to ½" nylon double braid. Approximate lengths: 100' 7/8"; 100' ¾"; 120' ½"

45,000 lb displacement: Drogue would have 156 cones on 335' line. Line should taper from 7/8" or 1" to ¾" to ½" nylon double braid. Approximate lengths: 100' 7/8"; 100' ¾"; 135' ½"

50,000 lb displacement: Drogue would have 164 cones on 349' line. Line should taper from 7/8" or 1" to ¾" to ½" nylon double braid. Approximate lengths: 110' 7/8"; 110' ¾"; 125' ½"

60,000 lb displacement: Drogue would have 172 cones on 360' line. Line would be 7/8" or 1" tapering to ¾" and then to ½" for the last 75 cones.

70,000 lb displacement: Drogue would have 180 cones on 370' line. Approximate lengths: 135' 1" nylon double braid, tapering to approx 110" ¾", tapering to 125" 1/2" nylon.



Please email AceSailMakers@yahoo.com or
call us at (860) 739-5999 for pricing.
